UM1817
3.16
Smart card connector CN19
Pin number
1
2
3
4
17
5
6
7
8
18
Figure 20. Smart card connector CN19
Table 29. Smart card connector CN19
Detection pin of card presence
Detection pin of card presence
DocID026902 Rev 2
Description
VCC
RST
CLK
NC
GND
NC
I/O
NC
Connector
37/58
