UM1817
Pin Description
18
20
22
24
26
28
30
32
34
36
38
40
42
44
46
48
50
52
3.7

MicroSD connector CN8

Table 22. Daughter board extension connector CN7 (continued)
Alternative Function
PB10 HDMI_CEC
PE14 SPI1_MISO
PF11
VDD
PF1 OSC_OUT
PE9 SPI1_MOSI_DIR
GND
PE7
PB1
PC4
PA6 Audio_IN
PA5 Aduio_OUT_RIGHT
PE13 SPI1_SCK
PA3 SmartCard_RST
PA1
PF3 8xUSART7_RX
GND
PC3 SmartCard_OFF

Figure 13. MicroSD connector CN8 (front view)

DocID026902 Rev 2
How to disconnect with function block
BOOT0
-
-
LED3
-
-
LDR_IN
-
on STM32091C-EVAL board
Remove R12
Remove R45
Remove R46, open JP4
-
Remove R56, Close SB14
Remove R81
-
Remove R163
-
-
Remove R107
Keep JP14 open
Remove R74
Remove R136
Remove R7
No Jumper mounted on CN1
-
Remove R135
Connector
31/58
