Chapter 1 Starting Interface Configuration (ASA 5510 and Higher)
Detailed Steps
Command
Step 1
interface redundant number
Example:
hostname(config)# interface redundant 1
Step 2
member-interface physical_interface
Example:
hostname(config-if)# member-interface
management 0/0
Step 3
member-interface physical_interface
Example:
hostname(config-if)# member-interface
management 1/0
Examples
The following example creates two redundant interfaces:
hostname(config)# interface redundant 1
hostname(config-if)# member-interface gigabitethernet 0/0
hostname(config-if)# member-interface gigabitethernet 0/1
hostname(config-if)# interface redundant 2
hostname(config-if)# member-interface gigabitethernet 0/2
hostname(config-if)# member-interface gigabitethernet 0/3
What to Do Next
Optional Task:
•
Required Tasks:
•
•
Configure VLAN subinterfaces. See the
section on page 1-31.
For multiple context mode, assign interfaces to contexts and automatically assign unique MAC
addresses to context interfaces. See the
For single context mode, complete the interface configuration. See the
Interface Configuration (Routed Mode),"
(Transparent Mode)."
Starting Interface Configuration (ASA 5510 and Higher)
Purpose
Adds the logical redundant interface, where the number argument
is an integer between 1 and 8.
Note
You need to add at least one member interface to the
redundant interface before you can configure logical
parameters for it such as a name.
Adds the first member interface to the redundant interface.
See the "Enabling the Physical Interface and Configuring
Ethernet Parameters" section on page 1-23
physical interface ID.
Redundant interfaces do not support Management slot/port
interfaces as members.
After you add the interface, any configuration for it (such as an IP
address) is removed.
Adds the second member interface to the redundant interface.
Make sure the second interface is the same physical type as the
first interface.
To remove a member interface, enter the no member-interface
physical_interface command. You cannot remove both member
interfaces from the redundant interface; the redundant interface
requires at least one member interface.
"Configuring VLAN Subinterfaces and 802.1Q Trunking"
"Configuring Multiple Contexts" section on page
or Chapter 1, "Completing Interface Configuration
Cisco ASA Series CLI Configuration Guide
for a description of the
1-15.
Chapter 1, "Completing
