Visually inspect both of the belts for wear or tear. If any damage to the belt is
discovered, the belt must be replaced. Check the tension of the belt. If the belt is
loose, it must be tightened.
described in the Installation and Service manual.

7.6 CLEANING THE MSCU AIR FILTERS AND FAN

The MSCU air filters and fans are located as shown in the above figure. They should
be cleaned regularly to ensure proper ventilation and prevent excessive rise in electric
component temperatures. Pull out the filter cover to access the filter. Take the filter
out and clean with water.
ventilation fan with a damp cloth.
Make sure water does not drip into the open circuitry in the MSCU during
cleaning. Permanent electrical damage can occur.
The procedure to replace and tighten the belt is
Ensure the filter is dry before replacing.
MSCU AIR FILTER
Page 60
Clean the
MSCU FAN
