Simuline Cycraft Installation & User Manual page 26

The processes to place Rubber Pads and adjust the Leg Levelers are as follows:
1) Make sure that all of the four adjustable Leg Levelers are not touching the ground.
If it is, raise it so that only the three rubber pads touch the ground. The center of
mass of Cycraft is very near the central rear rubber pad.
advisable to have two people stand on top of the front two rubber pads to make
sure the three pads are touching the ground securely.
2) Lower the 4 adjustable Leg Levelers so that they touch the ground and evenly
hold the weight of Cycraft. Do not extend them so much that the central rubber
pad is raised from the floor.
Adjusting Nut
3) After you are satisfied that the pads are set correctly, you can proceed to
assemble Cycraft. However, after assembly, the pads should be observed during
the test runs and adjusted further if there seems to be excessive movement or
uneven loading and lifting of the pads.
5.5 CONNECTING THE HEAVE ACTUATOR
At no time during the installation and assembly process should personnel
place body parts or go beneath the cabin. Take note that there is always the
danger of the cabin falling.
1) Install the turnbuckle firmly between the frame and rocker arm as shown.
Level Pad
Page 26
Therefore, it is
To secure the machine,
turn the adjusting nut
clockwise.
