Simuline Cycraft Installation & User Manual page 58

Inspection Part Picture
Point
A
B
C
D
E
F
How to check
Hexahead bolt M12 x 8 points
Lower joint of heave actuator is inside of
MSCU so in order to inspect the bolts, the
MSCU cover must be removed.
Hexahead bolt M12 x 8 points
Hexahead bolt M12 x 4 points
Hexahead bolt M10 x 8 points
Hexahead bolt M10 x 4 points (Lower)
Hexahead nut M10 x 4 points (Upper)
