8,9
Safety Photo Sensors &
Reflectors
10
Safety Floor Sensor
11~
Safety Floor Sensor Plates 11 = A type, 12 = B type, 13 = C type,
14
15
Floor
Sensor
Lamp
16
Safety Link
17
Heave Actuator Joint
18
Rocker Arm
19
Start Button
20
View Button
21
Game Stop Button
22
Video Control Buttons
23
Steering Wheel
24
Accelerator Pedal
25
Brake Pedal
26
Monitor
27
Front Speakers
28
Rear Speakers
29
Subwoofer
There are 2 photo sensors on each side of the
outer frame.
obstructed, the simulator will stop in its current
orientation until 3 seconds after the removal of
the obstruction.
The metal floor plate underneath the cabin is a
pressure sensor that stops the simulators
motion when stepped on.
begin to move again 3 seconds after the
removal of the pressure.
14 = D type
Indicator
Lamp (Green) goes off when the floor sensor is
activated.
Safety link connected to the rocker arm.
Tilts up and down to create heave motion.
Begins the game after coin is inserted.
Changes the driver's view perspective during
play.
Terminates the game and lowers the cabin to
the initial position.
Removing this cover exposes the control
buttons to adjust video screen parameters.
Refer to Chapter 2 for details.
Produces steering input for the game.
Produces accelerator input for the game.
Produces braking input for the game.
Displays game graphics.
Produces audio effects.
Produces audio effects.
Produces audio effects with low frequency
Page 18
If any of the sensor lines are
The simulator will
