All inspections described below must be performed with all electrical POWER
OFF. Attempting to carry out the processes with the power ON can cause
serious injury to personnel due to abrupt motion and electrical shock.

7.2 INSPECTION OF CRITICAL BOLTS AND CONNECTIONS

The above figures indicate the location of critical bolts on Cycraft. These bolts hold
up the cabin and can cause the cabin to drop if they come loose. They are marked
with a white line after assembly so that misaligned marking lines can identify loose
bolts easily.
E
D
Page 57
C
F
A
B
