Simuline Cycraft Installation & User Manual page 48

INDICATOR
Power Pilot Lamps
Normal LED (Green)
Driving LED (Green)
Control Error LED (Red)
Safety Sensor LED (Red)
Seat Belt LED (Red)
LCD Display
CAN TCP
1) 43 2) 43
LCD Display After Power ON
CAN = Control Area Network
TCP = Telephony Connection Protocol or (LAN = Local Area Network)
NOR = Normal Operation (All Systems OK)
The SYSTEM SHUT DOWN Sequence can be initiated at any time by pressing the
red "SYSTEM OFF" button for about 2 seconds. The cabin monitor will turn off and
the cabin will glide down to the nose down rest position. Then, the main powers to
the computers and other components will shut off automatically.
Before turning off the power, MAKE SURE THERE IS NO PERSON OR
OBSTACLE NEAR OR UNDER THE CABIN. The cabin will glide down upon
power off and can cause serious damage or injury.
Items (page 45)
5
6-1
6-2
6-3
6-4
6-5
7
NOR
3) 43
Page 48
CONDITION
All 4 l a m ps Cycraft Sets OK
ON (Green)
ON (Green) Will turn off when
driving starts
OFF Will turn on when
driving starts
OFF ON @ Error
OFF/ON Will turn on if photo
sensor or floor
sensor is activated.
OFF/ON Will turn on if seat
belt is not locked.
See below CAN – TCP - NOR
CAN TCP
1) 8043 2) 8043
LCD Display when GAME is ON
REMARK
NOR
3) 8043
