Simuline Cycraft Installation & User Manual page 17

22
19
20
No. Item
1 Cabin (Seat + Monitor)
2 Main Frame
3 Actuators
4 Motion System
Unit (MSCU)
5 Coin Chute Tower
6 Motion Stop Switch
7 Operator Panel
26
29
25
Description
Carries the player and moves during operation.
Holds
electronics.
Three electric linear actuators that move the
cabin in 3 DOF (degrees of freedom). The two
actuators on top of the cabin creates pitch and
roll motions.
creates heave motion.
Cabinet Houses all the control electronics and electrical
components.
Carries the coin chute mechanism.
Pressing this button will stop the simulator
motion but game play will continue.
resumes 3 seconds after the switch is released.
This button can be used in case of emergency
when motion must be stopped.
Houses indicators and switches to set and
control Cycraft. Refer to Chapter 2 for details.
Page 17
24
the cabin, actuator
The actuator behind the cabin
27
21
23
system and
Motion
