Operating Instructions
TSZ-UNI
4.2
Survey and construction
Fig.1
TSZ-uni (standard)
Fig. 2
1.1
Technical Data
Type:
Gripping range W
TSZ-uni
50 – 600 mm
(2- 23½")
11 / 22
General
TSZ-uni (with accessories A 43100867 )
Fig. 3
Inside height E
Carrying capacity
185 mm
600 kg
(7¼")
(1.320 lbs)
V4
1
Suspension lug
2
Handles
3
Adjustment of gripping
range
4
Assembly plate for height
adjustable support
(43100867)
5
Spring bolt (for gripping
range adjustment)
6
Rubber gripper bar (PGL3)
7
Automatic release
A
Height adjustable support
(43100867)
Gripper lenght L
Dead weight
350 mm
~ 30 kg
(13¾")
(~ 64 lbs)
