Operating Instructions
TSZ-UNI

3 Safety

3.1

Safety symbols

Danger to life!
Identifies imminent hazard. If you do not avoid the hazard, death or severe injury will result.
Hazardous situation!
Identifies a potentially hazardous situation. If you do not avoid the situation, injury or damage to property can
result.
Prohibition!
Identifies imminent a prohibition. If you do not avoid the prohibition, death and severe injury, or damage to
property will result.
3.2

Explanation of basic concepts

Gripping range:
Gripping good (s):
Opening width:
Immersion depth:
Device:
Product dimensions:
Dead weight:
Load capacity:
3.3

Definition skilled worker / specialist

Only skilled workers or specialists is it allowed to carry out the installation,- maintenance, - and repair work on these
device!
Skilled workers or specialists must have for the following points (if it applies for
these device), the necessary professional knowledge.
5 / 22
●
specify the minimum and maximum product measurements of the gripping good, which can
be gripped with this device.
●
is the product, which will be gripped or transported.
●
consists of the gripping range and the measure to drive over the gripping good.
gripping range + measure to drive over the gripping good = opening width
●
is the maximum gripping height of gripping goods, conditional of the height of the gripping
arms of the device.
●
is the description for the gripping device.
●
Are the dimensions of the gripping good (e.g. length, breadth, height
of the product).
●
is the own weight (without gripping good) of the device.
●
specify the maximum possible load of the device (lifting of gripping goods).
Safety
V4
●
for mechanic
●
for hydraulics
●
for pneumatics
●
for electrics
