Operating Instructions
FTZ-UNI-15
4.2
Survey and construction
Bolt for eyelet
Upper part
Telescope-tube
Handle to control the
FTZ-UNI-15
Spring bolt to adjust the
gripping range
Fixingholes for vertically adjustable
rubberplate (special accessories)
Gripping arm
Rectangle tube for
gripping range
Rubber gripper
Gripper lengh
4.3 Technical data
The exact technical data ( carrying capacity, dead weight, etc.) are listed on the type plate.
10 / 19
General
Opening range
V7
Automatic release to adjust
fullautomatically gripping and
opening
Handle to control the
FTZ-UNI-15
Gripping arm
Depth
GB
