5 Installation

1.2

Mechanical connection

5.1.1

Suspension lug

●
The device is equipped with a suspension lug and can be mounted on various support frames/lifting devices.
●
Take careful that the suspension lug is safety joined with the crane hook and can not slip down.
●
The maximum carrying capacity of the support frame/lifting device is not allowed to cross over by the
dead weight of the device and the maximum load.
5.1.2

Load hook and chains

●
Fit suspension ring in the load hook of the lifting equipment.
●
Ensure that the single chains are not twisted and may be easily pulled through the jaws
●
Attaching the device to the lifting equipment take care that all local safety regulation is observed.
●
It is not allowed to exceed the carrying capacity of the lifting equipment with the device and the maximum
load.

6 Adjustments

6.1

Adjustment - gripping range

Before the product can be lifted and transported, the gripping range has to be adjusted to the dimensions of
the product.
●
Caution while adjusting of the gripping range. There is danger of injuring the hands!
●
The adjustment of the gripping range may never take place on both sides at the same time.
Always adjust the gripping range first to the one and then on the other side.
●
Pull the spring bolt (5) upwards, rotate around 180° and lock in position (in nick).
●
Move the rectangular tube (3), until the gripping range is approx. 5 cm larger than the gripping good.
●
Pull the spring bolt (5) upwards again and rotate around 180°.
●
Move the rectangular tube (3) so long, until the spring bolt engages in one of the holes.
●
The adjustment of the gripping range has to follow general symmetrical.
That means, it must be used in each case the same adjustable hole with both rectangular tubes (3).
