Quick Guide
1 1
Surroundings
Enclosure
Enclosure kit available.
Vibration test
Max. relative humidity
Aggressive environment (IEC 60721-3-3), coated (standard) frame H1-H5
Aggressive environment (IEC 60721-3-3), non-coated frame H6-H10
Aggressive environment (IEC 60721-3-3), coated (optional) frame H6-H10
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature
Derating for high ambient temperature, see .
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance, enclosure frame H1-H5
Minimum ambient temperature at reduced performance, enclosure frame H6-H10
Temperature during storage/transport
Maximum altitude above sea level without derating
Maximum altitude above sea level with derating
Derating for high altitude, see
Safety standards
EMC standards, Emission
EMC standards,
Immunity

1.8 Special Conditions

1.8.1 Derating for Ambient Temperature and Switching Frequency

The ambient temperature measured over 24 hours should be at least 9 °F [5 °C] lower than the max. ambient temperature.
If the adjustable frequency drive is operated at a high ambient temperature, the continuous output current should be
decreased. For derating curve, see VLT

1.8.2 Derating for Low Air Pressure

The cooling capability of air is decreased at low air pressure. For altitudes above 6,600 feet [2 km], contact Danfoss
regarding PELV. Below 3,300 ft [1,000 m] altitude, no de-rating is necessary, but above 3,281 ft [1,000 m], the ambient
temperature or the maximum output current should be decreased. Decrease the output by 1% per 330 ft [100 m] altitude
above 3,300 ft [1,000 m] or reduce the max. ambient temperature by 1° per 660 ft [200 m].
1.9 Options for VLT
For options, see the VLT

1.10 MCT 10 Support

MCT 10 Set-up Software information is available at: www.danfoss.com/BusinessAreas/DrivesSolutions/fc101driveupdates
46
Quick Guide
See max. output current at 104/122 °F [40/50 °C] in chapter 1.7.2 Line Power Supply 3x380–480 V AC
EN 61800-3, EN 61000-3-12, EN 61000-6-1/2, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN
®
HVAC Basic Design Guide.
®
HVAC Basic Drive FC 101
®
HVAC Basic Drive FC 101 Design Guide.
Danfoss A/S © Rev. 2014-01-22 All rights reserved.
5%–95% (IEC 60721-3-3; Class 3K3 (non-condensing) during operation
EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
IP21, TYPE 1
Class 3C3
Class 3C2
Class 3C3
32 °F [0 °C]
-4 °F [-20 °C]
14 °F [-10 °C]
-22 to +149/158 °F [-30 to +65/70 °C]
3,300 ft [1,000 m]
10,000 ft [3,000 m]
EN/IEC 61800-5-1, UL 508C
61000-4-5, EN 61000-4-6
MG18A522
IP20
1.0 g
