Quick Guide
RFI Filter
Conduct emission. Maximum shielded cable length [m]
Type
Industrial environment
EN 55011 Class A2
Without With
external external
filter filter
30–125 hp
[22–90 kW]
3x380–480 V
IP54
Table 1.31 Test Results
1.7.5 General Specifications
Protection and features
•
Electronic thermal motor protection against overload.
•
Temperature monitoring of the heatsink ensures that the adjustable frequency drive trips in case of overtem-
perature.
•
The adjustable frequency drive is protected against short-circuits between motor terminals U, V, W.
•
When a motor phase is missing, the adjustable frequency drive trips and issues an alarm.
•
When a line phase is missing, the adjustable frequency drive trips or issues a warning (depending on the load).
•
Monitoring of the intermediate circuit voltage ensures that the adjustable frequency drive trips when the
intermediate circuit voltage is too low or too high.
•
The adjustable frequency drive is protected against ground faults on motor terminals U, V, W.
Line power supply (L1, L2, L3)
Supply voltage
Supply voltage
Supply voltage
Supply frequency
Max. temporary imbalance between line phases
True Power Factor (λ)
Displacement Power Factor (cosφ) near unity
Switching on the input supply L1, L2, L3 (power-ups) enclosure frame H1-H5, I2, I3, I4
Switching on the input supply L1, L2, L3 (power-ups) enclosure frame H6-H8, I6-I8
Environment according to EN 60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical Amperes, 240/480 V
maximum.
Motor output (U, V, W)
Output voltage
Output frequency
Switching on output
Ramp times
MG18A522
Quick Guide
Housing, trades and
light industries
EN 55011 Class A1 EN 55011 Class B
Without With Without
external external external
filter filter filter
25 10
Danfoss A/S © Rev. 2014-01-22 All rights reserved.
Radiated emission
Industrial
environment
EN 55011 Class A1
With Without With
external external external
filter filter filter
Yes
3.0% of rated supply voltage
≥ 0.9 nominal at rated load
overvoltage category III/pollution degree 2
0–100% of supply voltage
0–200 Hz (VVC
1
Housing, trades and
light industries
EN 55011 Class B
Without With
external external
filter filter
No
200–240 V ±10%
380–480 V ±10%
525–600 V ±10%
50/60 Hz
(>0.98)
Max. 2 times/min.
Max. 1 time/min.
plus ), 0–400 Hz (u/f)
Unlimited
0.05–3600 s
43
1
