Optional accessories

Bar-code scanners

The Euro-50iTE Mini cash register should by optionaly equipped with an interface for connecting a bar-code
scanner. If you decide to use a bar-code scanner, this section offers some recommendations for how to choo-
se one. In each case we recommend buying and connecting a scanner with the help of your local Euro-50iTE
Mini dealer.
We connect a bar-code scanner to the cash register via optional a built-in serial RS-232 interface. The bar-
-code scanner must be equipped with the same interface. For a scanner connection, the cash register offers
a single direction +5V adapter for the COM1 (Port1) port; if you are using the COM2 port (Port2) to connect
the scanner, you must use an external connection. Prior to connecting a scanner it is necessary to correctly
program both the scanner and the cash register. We recommend using a scanner with its own connection.
We recommend Metrologic scanners for working with the cash register. Ask your Euro-50iTE Mini dealer
for more information.
Figure 7.1 - PC keyboard layout the E50i
