Cash register characteristics
INSTALLATION OF THE PAPER TAPE
The Euro-50TE Mini cash register uses one thermal paper tape with width 57mm. This tape is used for prin-
ting of the customer receipt. The cash register saves the control receipt in electronic form. We recommend
to use only rolls of good quality with the maximum roll diameter of 45 mm. For good functionality of the cash
register, make sure of the correct printing saturation. If any problems occur, contact your local authorized
dealer of Euro-50TE Mini.
Figure 2.6 – Installation of paper ribbons into the cash register
release lever (2)
the paper-feed
button (4)
Procedure of paper tape installation for Euro-50TE Mini ( according to Figure 2.6):
•
By pulling the lever (2) open the paper cover and paper roller (3)
•
Take out empty reel with the bar
•
Put the new paper ribbon on bar an put it on the original place
•
Hold the end of the paper over the operator display and close the paper cover (3) to its original position
(you should hear a click at closing the paper roller (3) )
•
Press the key for sliding the paper to ensure about the correct installation of the paper ribbon
20
printer roller
Figure 2.7 –Opening the cover tape
ribbon cover (1)
printer roller (3)
