RAVAGLIOLI S.p.A.
14 TROUBLES
Some of the most common problems that could arise on wheel aligners are listed here below.
Ravaglioli S.p.A. declines all liability for injury or damage to persons, animals and
properties caused by the intervention of unauthorised personnel, and by the use of non-
original spare parts.
Before doing any operation on the system, always disconnect the power supply.
In case of doubt, do not interpret, but contact RAVAGLIOLI S.p.A. technical assistance in
order to obtain instructions suitable for performing operations in total safety.
TROUBLE
NO OPERATION
Monitor does not work
PC cannot be switched on
Printer does not work
(see also printer user's manual)
15 MAINTENANCE
WARNING!
Before doing any maintenance job, the machine will have to be disconnected
from the power mains.
To clean plastic panels or surfaces use alcohol (AVOID USING LIQUIDS CONTAINING
SOLVENTS).
DISPLAY shall be cleaned with a dry cloth; if very dirty, clean it with a moist cloth, then dry it.
Do not spray the alcohol directly on the control panel and do not clean using strong jets of
compressed air.
Keep optical unit methacrylate filters clean using a slightly moist cloth, do not use solvents;
Printer cleaning, cartridge replacement and any other maintenance operation on printer are
described in the manual supplied with the printer itself. Always refer to this manual before
carrying out any maintenance operation on printer.
16 STORAGE AND SCRAPPING
Storage - If the machine has to be stored for a long period of time, disconnect all supply lines and
protect the display screen, which could be damaged by excessive dust.
Grease any parts liable to be damaged by dryness.
Scrapping - If the machine is to be no longer used, it must be made inoperative:
All those parts that could represent a potential hazard risk must be correctly disposed of. Dispose
of parts according to category.
Scrap as iron scrap through authorised channels.
Parts considered as special waste must be removed and split up according to type and then
disposed of through authorised channels according to applicable regulations.
RAVTD3000 - RAVTD3000HP
RAVTD3000NRC - RAVTD3000ATS
CAUSE
- No mains voltage
- Interrupted protection fuses
- No supply voltage
- No video signal
- No supply voltage
- No supply voltage
- No signal
RAVAGLIOLI S.p.A. - Via I° Maggio, n° 3 (Pontecchio Marconi)
40037 Sasso Marconi (Bologna - Italy)
Tel. 051/ 67.81.511 – Fax 051/ 84.64.67 E-mail: rav@ravaglioli.com
Instruction manual
Code M0215 - rev.1.1
REMEDY
- Check mains voltage
- Check protection fuses
- Check power cable connection
- Check video signal cable connection
between PC and monitor
- Check PC ON/OFF switch
- Check power cable connection
- Check ON/OFF voltage
- Check power cable connection
- Check printer signal cable connection with
PC
(11/2012)
Page 51/52
