9 PROGRAMME CONFIGURATION

To proceed to programme configuration, select F2
explained in par. 10.1 on page 22.
You will enter a configuration menu allowing editing the different programme characteristics
according to your needs.
Language selection: You can select your dialogue language among the many available ones.
Configuration: programme will display the screen of Figure 14
You can edit system parameters, database profile, specify which parts are fitted on the
machine, parts type, make a Bluetooth search to couple measuring heads with cabin.
Print Menu: Print can be customised by entering workshop data, selecting the type of
desired printout, and selecting the pre-set printer (if more than one printer is connected).
Backup / Restore: In order not to run the risk to lose any vehicle and customer database
data, it is recommended to create a backup copy (data saving). We recommend using a "flash
disc" USB key for this process.
Lost or deleted data can be restored if the backup operation has been carried out, thanks to
the restore procedure.
Additional functions: programme displays screen Figure 57, from which you can access
TEST or sensor Calibration applications (reserved to skilled and authorised personnel), and
the "DATABASE MANAGEMENT", see chap. 12
RAVTD3000 - RAVTD3000HP
RAVTD3000NRC - RAVTD3000ATS
Figure 13
DETECTOR
KEYPAD
RAVAGLIOLI S.p.A. - Via I° Maggio, n° 3 (Pontecchio Marconi)
40037 Sasso Marconi (Bologna - Italy)
Tel. 051/ 67.81.511 – Fax 051/ 84.64.67 E-mail: rav@ravaglioli.com
from the introduction page, as
PC KEYPAD
Instruction manual
Code M0215 - rev.1.1
(11/2012)
DESCRIPTION
It goes back to the
introduction page.
(par. 10.1 on page 22)
It moves selection up.
It moves selection down.
It confirms selection.
Page 19/52
