10.13 Summary of DIAGNOSIS and ADJUSTMENT data

This page is displayed when vehicle adjustment has been completed, after pressing F4 in the
front adjustment phase, see Figure 38.
Summary of
Summary of
adjustment
diagnosis data
carried out
Figure 41
DETECTOR PC KEYPAD DESCRIPTION
KEYPAD
It displays the additional
function menu. See par.
10.14
It displays vehicle technical
specification page.
Operations completed!
Customer data entry and
printout. See par. 10.15
It returns to rear adjustment
phase.
See par. 10.11
