10.4 Selected Vehicle Technical Specification Displaying

When selecting a vehicle (see par. 10.3 on page 25), a page showing the measurements and
tolerances supplied by the manufacturer is displayed.
(*) Key description
Possibility to enter
chassis height or
kingpin data, as
envisaged by the
manufacturer
RAVTD3000 - RAVTD3000HP
RAVTD3000NRC - RAVTD3000ATS
Figure 23
DETECTOR
KEYPAD
Press F5
To display any graphic
animation
RAVAGLIOLI S.p.A. - Via I° Maggio, n° 3 (Pontecchio Marconi)
40037 Sasso Marconi (Bologna - Italy)
Tel. 051/ 67.81.511 – Fax 051/ 84.64.67 E-mail: rav@ravaglioli.com
PC KEYPAD
It displays vehicle technical
specifications next page, and
Instruction manual
Code M0215 - rev.1.1
(11/2012)
DESCRIPTION
It goes back to vehicle
selection
(par.10.3 on page 25)
See
(*) Key description
any graphic animation
See (*) Key description
It changes rim diameter
value
It goes to out-of-centre
operations
(par.10.5 on page 28)
