(***) The system takes some seconds to complete the correct target recognition. During this
phase and during the following measuring phases, the symbols displayed on the bottom right
side of the screen show the progress of the 4 target recognition. See legend below.
= Target NOT recognized (GREY symbol)
= Target recognized and in the process of being optimized (GREY symbol)
= Target recognized and optimized / invalid measures (YELLOW symbol)
= Target recognized and optimized / valid measures (GREEN symbol)
= Target not required in this phase (BLACK symbol)
ALWAYS take special care when positioning the vehicle on the lift. It should be as centred as
possible to speed up and optimise both target search and connection and the following
measuring operations.
