10 VEHICLE DIAGNOSIS AND ADJUSTMENT

10.1 Introduction Page

Upon machine switching on (see par. 6.1 on page16), programme start screen will be
displayed. You can select different functions.
Press F4 to continue.
Page 22/52
RAVTD3000 - RAVTD3000HP
RAVTD3000NRC - RAVTD3000ATS
Figure 18
DETECTOR
KEYPAD
