10.12.1 Front toe-in adjustment with steered wheels

Front toe-in adjustment procedure with steered wheels is started by pressing F3 from front
adjustment page
The following picture, requesting to steer left or right, will be shown. Press F5 to confirm.
Note: Steering level indicator is displayed only to give the operator a reference of the value,
which should remain within the maximum alignment reading range (about 22÷24°).
After pressing F5, the page shown in Figure 40 will be displayed. "De-freeze" to enable
carrying out of partial toe-ins. Use F2
toe-in).
When adjustment has been completed, press F1
phase (par. 10.12). The programme will request to steer back toward the centre before the
front adjustment page is displayed (Figure 38).
Page 36/52
RAVTD3000 - RAVTD3000HP
RAVTD3000NRC - RAVTD3000ATS
.
Figure 39
Figure 40
DETECTOR
KEYPAD
RAVAGLIOLI S.p.A. - Via I° Maggio, n° 3 (Pontecchio Marconi)
40037 Sasso Marconi (Bologna - Italy)
Tel. 051/ 67.81.511 – Fax 051/ 84.64.67 E-mail: rav@ravaglioli.com
(LH partial toe-in) or F3
to return to front adjustment
PC KEYPAD
adjustment page display.
It de-freezes / freezes LH
It de-freezes / freezes RH
Instruction manual
Code M0215 - rev.1.1
(11/2012)
(RH partial
DESCRIPTION
It returns to front
partial toe-in
partial toe-in
