10.3 Vehicle Make and Model Selection

Press F4 to select vehicle make and model. Programme shows the list of the makes
of the selected group (see Figure 22),
Or press F5 to start a search using keys (model/make/year) or the
(Vehicle Identification Number) which is a unique serial number used by the automobile
industry to identify motor vehicles. V.I.N. consists of a 17-alphanumeric digit plate usually
positioned inside engine compartment. See Figure 21
Note: by pressing F5
model/year, or VIN (Figure 21) or through a manual selection (Figure 22).
Enter vehicle
V.I.N. number
here
Press to move cursor from "model name" to "V.I.N." entering field.
Press to continue, and display the list of all the vehicles complying with the just-
entered search criteria; then select the correct vehicle and display the page of the selected
vehicle technical specifications (par. 10.4)
RAVTD3000 - RAVTD3000HP
RAVTD3000NRC - RAVTD3000ATS
Figure 20
you select the search mode: Through search keys such as Make name,
Figure 21
RAVAGLIOLI S.p.A. - Via I° Maggio, n° 3 (Pontecchio Marconi)
40037 Sasso Marconi (Bologna - Italy)
Tel. 051/ 67.81.511 – Fax 051/ 84.64.67 E-mail: rav@ravaglioli.com
.
Instruction manual
Code M0215 - rev.1.1
(11/2012)
List with different
database profiles
(par. 9.1 on page
20)
V.I.N number
Enter vehicle model
(max. 3 words of at
least 3 characters
each).
It is recommended to
enter also vehicle
make.
You can also enter the
year of manufacture (4
digits, compulsorily)
