A report on the performed test is printed with customer data, vehicle data before and after
adjustment, vehicle technical specifications supplied by manufacturer, and any other remarks for
the customer.
To access the data contained inside customer database, press F3
Figure 18)
Legend of the printout example shown in the previous page (Figure 45).
1 - RAVAGLIOLI logo of the manufacturer
2 - Space dedicated to workshop data customisation
3 - Test date and time
4 - Vehicle being tested and vehicle owner data
5 - Vehicle being tested manufacturing data
6 - Vehicle being tested diagnosis data
7 - Vehicle being tested data after adjustment
8 - Front axle data table
9 - Rear axle data table
10 - Space devoted to manual remarks
Page 40/52
RAVTD3000 - RAVTD3000HP
RAVTD3000NRC - RAVTD3000ATS
DETECTOR
KEYPAD
RAVAGLIOLI S.p.A. - Via I° Maggio, n° 3 (Pontecchio Marconi)
40037 Sasso Marconi (Bologna - Italy)
Tel. 051/ 67.81.511 – Fax 051/ 84.64.67 E-mail: rav@ravaglioli.com
PC KEYPAD
