10.7 Vehicle alignment / direct measurement operations

To proceed to vehicle alignment and direct angle detection, you should have first carried out
measurement preliminary operations, as explained in par. 10.6 on page30 .
Processing
Front wheel
status
alignment level
display
Figure 31
DETECTOR KEYPAD PC KEYPAD DESCRIPTION
It goes back to
measurement
preliminary operations.
(par.10.6 on page 30)
When the alignment has been achieved, the "STOP" symbol is displayed, signalling that the
programme is taking the vehicle measurements. The programme proceeds automatically only
after the wheels have been aligned.
