Hardware ports, switches and LEDs
14.2.2

Connector supply voltage and DEBUG-interface

Pin assignment X2 (4-pole screw-plug connector, on the bottom side, at the back)
Pin No. Name
1 UB (Pwr)
2 0 V (Pwr)
3 Rx-Debug
4 Tx-Debug
Attention:
At isolated devices (option GT) Ground for the DEBUG-Interface must be
connected with pin 3 (AP-GND) of the RS-interface!
At devices that are not isolated also the 0V (Pwr)-signal can be used as
reference.
14.2.3

Profinet-connector

The plugs (labeled: RJ45 PROFINET-IO) for the connection to PROFINET are available on the
bottom side of the device.
Pin assignment X3 P1 (RJ45 up front, i. e. which is located closer to the front panel)
Pin No. Name
1 TD+
2 TD-
3 RD+
4
5
6 RD-
7
8
Pin assignment X3 P2 (RJ45 at the back, i. e. which is located closer to the DIN-rail)
Pin No. Name
1 TD+
2 TD-
3 RD+
4
5
6 RD-
7
8
14.2.4

Power supply

The device must be powered with 10-33 VDC, The voltage supply is made through the 4-pole
screw-plug connector at the device's bottom side.
Please note that the devices of the series UNIGATE
31 UNIGATE
Function
10..33 V supply voltage / DC
0 V supply voltage / DC
Receive signal Debug
Transmit signal Debug
Function
Transmission line +
Transmission line -
Receive line +
Receive line -
Function
Transmission line +
Transmission line -
Receive line +
Receive line -
®
fieldbus gateway UNIGATE
Deutschmann Automation GmbH & Co. KG
®
should not be operated with AC voltage.
®
CL - PROFINET 2Port V. 1.6 15.8.14
