LOCaTiON reQuireMeNTS

Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can
result in death, fire, or electrical shock.
iMPOrTaNT: Do not install or store the wash-
er where it will be exposed to the weather. Do
not store or operate the washer in tempera-
tures at or below 32°F (0°C). Some water can
remain in the washer and can cause damage
in low temperatures.
Proper installation is your responsibility.
You will need:
• A water heater set to deliver 120°F (49°C)
water to the washer.
• A grounded electrical outlet located within
4 ft (1.2 m) of where the power cord is
attached to the back of the washer.
See "Electrical Requirements."
• Hot and cold water faucets located within
4 ft (1.2 m) of the back of the washer,
and provide water pressure of 10-100 psi
(69-690 kPa). A pressure reduction valve
should be used in the supply line where
inlet pressure entering the building exceeds
100 psi (690 kPa) to prevent damage to the
washer mixing valve.
• A level floor with a maximum slope of 1"
(2.5 cm) under entire washer.
• A sturdy floor to support the washer weight
(washer, water and load) of 315 lbs (143
kgs).
• A 12" (30 cm) minimum riser to provide an
air cushion and prevent noise and damage
to valves for a single washer installation.
• A floor drain should be provided under the
bulkhead. Prefabricated bulkheads with
electrical outlets, water supply lines and
drain facilities should be used only where
local codes permit.
reCeSSeD area aND
CLOSeT iNSTaLLaTiON
This washer may be installed in a recessed
area or closet. The installation spacing is
in inches and is the minimum allowable.
Additional spacing should be considered for
ease of installation, servicing, and compliance
with local codes and ordinances. If closet
door is installed, the minimum unobstructed
air openings in the top and bottom are
required. Louvered doors with equivalent air
openings are acceptable.
2-2
