Remove Drive Cam - Maytag MAT14CS Service Manual

Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
1. Remove the brake assembly
(see page 4-56).
C clip
2. Remove the C clip with a small flat blade
screwdriver.
3. Slide the drive cam off the shaft.
• The T bearing is an integral part of the
washer operation. If it wears out you will
need to order a new basket drive which
comes as an assembly including a new T
bearing.

reMOve Drive CaM

4-57
T Bearing
