8. Remove the pressure switch air hose from
the air dome on the side of the tub. Then
pull the air tube out of the retainer loop on
the side of the tub.
9. Remove three tub support spring brackets
by removing the 1/4 inch hex head screw
that secures each bracket to the tub
support. Hold the bracket while removing
the screw since the spring is still attached to
the end of the bracket.
retainer
Loop
air hose
Bracket with
1 screw
4-29
10. The bracket has a locator tab that fits into
the hole next to the screw location. Be sure
to use the same screws to secure the tub
support brackets when reassembling the
washer. Rycon grease must be applied to
the spring hook where it connects to the
bracket.
11. Place your feet on the base rails to support
the base while making sure not to bend the
rails. Pull the tub up and off the spin tube to
remove the tub.
Locator tab
