- Page 1 COMMERCIAL TOP LOAD WASHER INSTALLATION, USER & SET-UP INSTRUCTIONS MODELS: MAT12CS, MAT12PD, MAT13MN, MAT13PN LEAVE THESE INSTRUCTIONS WITH THE OWNER MAYTAG COMPANY, NEWTON, IOWA 50208 2207647...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of fire, explosion, electric shock, property damage or injury to persons when using your appliance, follow basic precautions, including the following: 1. Read all instructions before using the appliance. It is for use only in washing, rinsing and spin drying household textiles and garments. - Page 3 16. Unplug power supply cord when not in use, before cleaning or carrying out any owner maintenance tasks on your clothes washer. 17. Do not repair or replace any part of the appliance or attempt any servicing. Repairs and servicing should only be carried out by qualified service personnel.
-
Page 4: Step 2 Install Washer
PARTS supplied for installation: Cable tie to secure drain hose to standpipe, 4 washers and 2 screens for water hoses inlet hose or laundry tub Locking cam Beaded tie to secure drain hose to cabinet (if required) STEP 1 PREPARE WASHER 1. -
Page 5: Hose Connection
If the supply cord is damaged, it must be replaced with a specially terminated cord by an authorized service agent or a similarly qualified person in order to avoid a hazard. Do not connect via a cord extension set or electrical portable outlet device. HOSE CONNECTION 1. -
Page 6: Siphon Break Installation
SIPHON BREAK INSTALLATION If a 91 cm (36 in.) minimum standpipe is not available, or for floor drain installation and in cases where a tight connection is made between the drain hose and drain (standpipe, etc.) the 12001586 siphon break accessory is required. -
Page 7: Step 3 Setup Washer
STEP 3 SETUP WASHER After the washer has been properly installed there are still a few steps required before the washer is ready for operation. Make the following revisions: CS MODELS (COIN SLIDE) These models are activated by coin slide in the control center. Install the coin slide (NOT provided with the product) as follows: First, remove coin slide actuator from accessory package that is found in the back of the coin vault. -
Page 8: Control Set-Up Procedures
GENERAL USER INFORMATION- PD & PN models BLANK DISPLAY – This condition indicates the appliance is inoperative. Enter set-up mode to view diagnostic code. “0 MINUTES” SHOWING IN DISPLAY – This condition indicates the appliance cannot be operated. Coins dropped during this condition will be stored in escrow but cannot be used until normal operation is restored by opening and closing the lid. -
Page 9: How To Use The Key Pads To Program The Controls
HOW TO USE THE KEY PADS TO PROGRAM THE CONTROLS 1. The LOWER LEFT key pad is used to adjust the values associated with set-up codes. Pressing the key pad will increment the value. Rapid adjustment is possible by holding the key pad down. 2. - Page 10 MONEY COUNTER OPTION 1.00 This option is either SELECTED ‘ON’ or NOT SELECTED ‘OFF’. Not Selected ‘OFF’. Selected ‘ON’. Press the LOWER RIGHT key pad 3 consecutive times to select ‘ON’ and 3 consecutive times to remove (Not Selected ‘OFF’.) Counter resets by going from ‘OFF’ to ‘ON’. Press the LOWER MIDDLE key pad once to advance to next code or permanently select money count option by the following procedure.
- Page 11 VAULT VIEWING OPTION A.00 This option is either SELECTED ‘ON’ or NOT SELECTED ‘OFF’. Not Selected ‘OFF’. Selected ‘ON’. Press the LOWER RIGHT key pad once for this selection. When selected, the money and/or cycle counts will be viewable (if counting is selected), when the coin box is removed. Press the LOWER MIDDLE key pad once to advance to next code.
-
Page 12: Exit From Set-Up Mode
J.Cd COIN OPTION Coin selected. Coins selected. Coins disabled. Press the LOWER RIGHT key pad 3 consecutive times for this selection. PN MODELS ONLY: Must be set for _d. Press the LOWER MIDDLE key pad once to advance to next code. PRICE SUPPRESSION OPTION L.00 This option causes the customer display to show ‘ADD’... -
Page 13: Diagnostic Codes
This mode is entered by depressing the LOWER RIGHT keypad for 1 second while in any of the set-up codes 1 through 6 anytime a diagnostic code is present, or while dAS displays if operating with Maytag Data Acquisition setup. -
Page 14: Top Load Washer Help Mode
This mode is entered by pressing the LOWER LEFT key pad while in special pricing option mode 2.XX (or while dAS displays if operating with Maytag Data Acquisition setup). In help mode, the LOWER MIDDLE key- pad can be used to advance through three help codes (displayed as 1h.XX, 2h.XX and 3h.XX). Pressing the LOWER RIGHT keypad while any of the help codes are displayed clears the help codes. - Page 15 INSTALLATION ACCESSORY KITS Part No. Description Application 12001875 Earthing Kit Additional external earth bonding kit. 12001585 Drain Hose Extension Extends drain hose for drain facilities higher than 1.2 m (4 ft.) 12001586 Siphon Break Used when an air-tight connection exists between drain hose and drain facility or for floor drain facilities.
