BaSiC OPeraTiON OF COMMerCiaL WaSHer

For additional information, see www.MaytagCommercialLaundry.com
This tech sheet is not valid for models prior to series MAT14.
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
GeNeraL uSer
iNFOrMaTiON
1. Blank display: This condition indicates the
appliance is inoperative. Enter set-up mode
to view diagnostic code. Ensure there is
power to the unit and the control.
2. '0 Minutes' showing in display: This
condition indicates the appliance cannot
be operated. Coins dropped or debit
inputs during this condition will be stored
in escrow, but cannot be used until normal
operation is restored by opening and closing
the lid. If the lid switch fails, it must be
replaced before normal operation can be
restored.
3. Cold start (initial first use): Appliance is
programmed at the factory as follows:
• 11 minute wash period
• 1 rinse with 2 minutes of rinse agitation
• $1.75 wash price (PD models)
• $0.00 wash price (PR models)
4. Warm Start (after power failure): After a
delay of up to 8 seconds, the appliance is
restored to the state that existed at time of
the power failure.
5. Pricing: After the lid is opened following
the completion of a cycle, the display
indicates the cycle price (unless set for free
operation). As coins are dropped or debit
inputs arrive, the display will change to lead
the user through the initiation of a cycle.
6. Free Cycles: This is established by setting
the cycle price to zero. When this happens
'SELECT CYCLE' will appear rather than a
cycle price.
7. Debit Card Ready: This appliance is debit
card 'cable' ready. It will accept a variety of
debit card systems; but does NOT come
with a debit card reader. Refer to the debit
card reader manufacturer for proper washer
set-up. In models converted to a Generation
1 debit card system, debit pulses represent
the equivalent of one Coin (coin 1).
8. Display: After the unit has been installed
and plugged in, the display will show '0
MINUTES'. Once the unit has been plugged
in and the washer lid opened the display
will show the price. In washers set for
free cycles the display will flash 'SELECT
CYCLE'.
