12 Speakerphone
key
13 Headset key
14 Navigation key/
Select key
15 Home key
16 Line keys
17 Screen
18 Message
Waiting
Indicator
19 USB Port

VVX 500 Series and VVX 600 Series Hardware

The following figure displays the hardware features on the VVX 500, 501, 600, and 601 business media
phones. The table lists each feature numbered in the figure.
VVX 500 series and VVX 600 series hardware features
Polycom, Inc.
Enables you to place and receive calls using the speakerphone. The key glows
green when activated.
Enables you to place and receive calls through a headset. The key glows
green when an analog headset is activated, and blue when a USB or Bluetooth
headset is activated.
Scrolls through information or options displayed on the phone's screen. Selects
a field of displayed data.
Displays the Home screen from other screens, and displays the Lines and
Calls screens from the Home screen.
Enable you to select a phone line, view calls on a line, or quickly call a favorite
contact.
Shows a 3.5-inch (8.89 cm) diagonal screen with a backlight that enables you
to view menus and data.
Flashes red to indicate when you have new messages.
Enables you to attach a USB flash drive or USB headset (VVX 411 only).
Getting Started with a VVX Business Media Phone
16
