Function
Name
code
PID
P17.23 reference
value
PID feedback
P17.24
value
Power factor
P17.25
of the motor
Current
P17.26
running time
Simple PLC
and the
current step
P17.27
of the
multi-step
speed
AC input
P17.35
current
Output
P17.36
torque
Counting of
P17.37 the motor
overload
P17.38 PID output
Wrong
P17.39 download of
parameters
P24 Group Water supply
Water
supply
P24.00
selection
Press
P24.01 feedback
source
Hibernation 0: Hibernate as the setting frequency﹤P24.03
P24.02
Detailed instruction of parameters
Display PID reference value
Range: -100.0~100.0%
Display PID response value
Range: -100.0~100.0%
Display the current power factor of the motor.
Range: -1.00~1.00
Display the current running time of the inverter.
Range:0~65535min
Display simple PLC and the current step of the
multi-step speed
Range: 0~15
Display the input current in AC side.
Range: 0.0~5000.0A
Display the output torque. Positive value is in the
electromotion state, and negative is in the power
generating state.
Range : -3000.0Nm~3000.0Nm
0~100 (100 is OL1 fault)
-100.00~100.00%
0.00~99.99
0: Disabled
1: Enabled
0: AI1 setting value (The inverter(≤15kW) can be
set by the analog potentiometer on the keypad
and AI1 setting is not available for the device
which is 18.5kW or higer than 18.5 kW)
1: AI2 setting value
2: AI3 setting value
3: HDI setting value
91
Function parameters
Default
Modify
value
●
●
●
●
●
●
●
●
●
0.00%
●
0.00
◎
0
○
0
◎
0
