INVT Goodrive 200A Operation Manual page 147

inverters
Goodrive200A
Model W1
0.75kW~2.2kW 150.2 115
4kW~5.5kW 170.2 131
7.5kW~15kW 191.2 151
18.5kW 250
22kW~30kW 275
37kW~55kW 270
75kW~110kW 325
132kW~200kW 500
37-110kW flange mounting
132-200kW flange mounting
Installation dimension (unit: mm)
W2 W3 W4 H1
130 7.5 234
150 9.5 292
174 11.5 370
210 234 12 375
237 259 11 445
130 261 65.5 555
200 317 58.5 680
180 480 60 870
H2 H3 H4
220 190 13.5
276 260 6
351 324 12
356 334 10
426 404 10
540 516 17
661 626 23
850 796 37
142
Appendix B
Installation
D1 D2
hole
155 65.5 5
167 84.5 6
196.3 113 6
216 108 6
245 119 7
325 167 7
363 182 9.5
358 178.5 11
