INVT Goodrive 200A Operation Manual page 77

inverters
Goodrive200A
Function
Name
code
electrical
level
detection
value
FDT2
retention
P08.35
detection
value
Frequency
arrival
P08.36
detection
value
Energy
P08.37 braking
enable
Threshold
P08.38
voltage
Detailed instruction of parameters
Setting range of P08.32: 0.00Hz~P00.03
(the Max. frequency)
Setting range of P08.33: -100.0~100.0%
(FDT1 electrical level)
Setting range of P08.34: 0.00 Hz ~P00.03
(the Max. frequency)
Setting range of P08.35: 0.0~100.0%
(FDT2 electrical level)
When the output frequency is among the below
or above range of the set frequency, the
multi-function digital output terminal will output
the signal of "frequency arrival", see the diagram
below for detailed information:
The setting range:0.00Hz~P00.03
(the Max. frequency)
This parameter is used to control the internal
braking unit.
0:Disable
1:Enable
Note: Only applied to internal braking unit. After
enabling, the overvoltage stall point will increase
by 20V more than the energy braking point.
After setting the original bus voltage, adjust this
parameter to break the load appropriately. The
72
Function parameters
Default
Modify
value
Hz
○
5.0%
○
0.00Hz
○
0
380V
○
voltage:
