INVT Goodrive 200A Operation Manual page 152

inverters
Goodrive200A
connecting to the drive.
Note: Check the insulation of the input power cables according to local regulations
before connecting the cables.
The inverter
GD200A -0R7G-4
GD200A -1R5G-4
GD200A -2R2G-4
GD200A
-004G/5R5P-4
GD200A
-5R5G/7R5P-4
GD200A -7R5G/011P-4
GD200A -011G/015P-4
GD200A -015G/018P-4
GD200A -018G/022P-4
GD200A -022G/030P-4
GD200A -030G/037P-4
GD200A -037G/045P-4
GD200A -045G/055P-4
GD200A -055G/075P-4
GD200A -075G/090P-4
GD200A -090G/110P-4
GD200A -110G/132P-4
GD200A -132G/160P-4
GD200A -160G/185P-4
GD200A -185G/200P-4
GD200A -200G/220P-4
GD200A -220G/250P-4
GD200A -250G/280P-4
GD200A -280G/315P-4
GD200A -315G/350P-4
GD200A -350G/400P-4
GD200A -400G-4
GD200A -500G-4
Note:
1. It is appropriate to use the recommended cable size under 40℃ and rated current. The
wiring distance should be no more than 100m.
2. Terminals P1, (+), PB and (-) connects the DC reactor options and parts.
Recommended cable size(mm
R,S,T
PE
U,V,W
2.5 2.5
2.5 2.5
2.5 2.5
2.5 2.5
4 4
6 6
10 10
10 10
16 16
25 16
25 16
35 16
50 25
70 35
95 50
120 70
150 70
185 95
240 95
120*2P 150
120*2P 150
150*2P 150
150*2P 150
185*2P 185
185*2P 185
95*4P 95*2P
95*4P 95*2P
120*4P 95*2P
147
2
)
P1(+) PB(+)(-)
2.5 2.5
2.5 2.5
2.5 2.5
2.5 2.5
2.5 2.5
4 2.5
6 4
10 4
10 6
16 10
16 10
25 16
35 25
50 25
70 35
95 35
120 70
150 95
185 50
95*2P 50
95*2P 50
95*2P 50
120*2P 95
120*2P 95
120*2P 95
150*2P 120
150*2P 120
95*4P 120
Appendix C
Screw
Terminal Tightening
screw torque
size (Nm)
M4 1.2~1.5
M4 1.2~1.5
M4 1.2~1.5
M4 1.2~1.5
M5 2~2.5
M5 2~2.5
M5 2~2.5
M5 2~2.5
M6 4~6
M6 4~6
M8 9~11
M8 9~11
M8 9~11
M10 18~23
M10 18~23
M10 18~23
M12 31~40
M12 31~40
M12 31~40
M12 31~40
M12 31~40
M12 31~40
M12 31~40
M12 31~40
M12 31~40
M12 31~40
M12 31~40
M12 31~40
