Function
Name
code
Polarity
selection of
P06.05
output
terminals
Y1
P06.06 switching-on
delay time
Y1
P06.07 switching-off
delay time
HDO
P06.08 switching-on
delay time
HDO
P06.09 switching-off
delay time
RO1
P06.10 switching-on
delay time
Detailed instruction of parameters
11:Lower limit frequency arrival
12:Ready for operation
13:Pre-magnetizing
14:Overload pre-alarm
15: Underload pre-alarm
16:Completion of simple PLC step
17:Completion of simple PLC cycle
18:Setting count value arrival
19:Defined count value arrival
20:External fault valid
21:Length arrival
22:Running time arrival
23:MODBUS communication virtual terminals
output
26: DC bus voltage establishment
27: Auxiliary motor 1
28: Auxiliary motor 2
The function code is used to set the pole of the
output terminal.
When the current bit is set to 0, input terminal is
positive.
When the current bit is set to 1, input terminal is
negative.
BIT0 BIT1
Y HDO
Setting range:0~F
The function code defines the corresponding
delay time of the electrical level change during
the programmable terminal switching on and off.
The setting range :0.000~50.000s
Note: P06.08 and P06.09 are valid only when
P06.00=1.
BIT2 BIT3
RO1 RO2
58
Function parameters
Default
Modify
value
○
0
○
0.000s
○
0.000s
○
0.000s
○
0.000s
○
0.000s
