Modbus Server – KNX
®
IntesisBox
Description Save the configuration (details in section 5.1.3)
Description Exits the configuration window.

5.1.3 Saving the configuration

When the configuration of the project is finished follow the next steps:
1. Click the button Save. Once accepted the pop-up message, that will save the project
in the folder on hard disk (more information in LinkBoxMB Manual).
2. You will be prompted to generate the configuration file to be sent to the gateway,
a. If YES is selected, the binary file (KNX.LBOX) containing the configuration for
the gateway will be generated and saved also into the project folder.
b. If NO is selected, the binary file needs to be created before following the next
steps. To do so open the Configuration window (section 5.1) and restart from
step 1.
3. Once in the configuration window again, click on exit. The configuration is ready to
be sent to the IntesisBox
The configuration cannot be received from the gateway to LinkBoxMB, it can only
be sent.
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
IntesisBox ® is a registered trademark of Intesis Software SLU
Save
Exit
® (check LinkBoxMB Manual).
