IntesisBox IBOX-MBS-KNX-100 User Manual page 18

Modbus Server – KNX
®
IntesisBox
1. Select the type of Modbus communication to use: TCP, RTU or TCP+RTU.
If Modbus TCP is selected, then:
2. IP IntesisBox:
192.168.100.246. If a wrong configuration is send or if there is any problem when
downloading the configuration, the default IP will be automatically set to allow
communication.
3. Net Mask: Enter the IP Net Mask for the gateway (supplied by the network
administrator).
4. Gateway: Enter the Default Gateway address (router address) in case the gateway
(IntesisBox) is in a different sub network than other Modbus devices (supplied by the
network administrator). Leave blank if there is no need of router address..
5. Port: Enter the TCP port to use, by default 502.
6. Timeout Keep Alive: Enter a value in seconds between 0 and 65535 (the default
value is 30s). This parameter defines the inactivity time of the incoming TCP
connection, after which the IntesisBox
checking. In case of detecting that the device that has established a TCP connection
with the IntesisBox
will be closed. This allows freeing up unused connections (IntesisBox
simultaneous Modbus-TCP connections). In any case, the minimum required time
from detecting inactivity in a TCP connection and closing it, in practice will never
lower than 1 minute.
If Modbus RTU is selected, then:
7. Connection: Select the connection used (EIA232 or EIA485).
8. Baud Rate: Select the baud rate.
9. Parity: Select the parity.
10. Slave: Enter the Modbus slave number for IntesisBox
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
IntesisBox ® is a registered trademark of Intesis Software SLU
Enter the IP address
® is unresponsive, the connection with this device (TCP socket)
for the
® will begin the process of TCP Keep-Alive
® .
URL http://www.intesisbox.com
Email info@intesisbox.com
tel +34 938047134
User's Manual r18 eng
IntesisBox, by default
® allows up to 4
18 /
31
