Summary of Contents for IntesisBox IBOX-ASCII-KNX
- Page 1 IntesisBox ® ASCII Server User's Manual v10 r14 eng...
- Page 2 ® User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX © Intesis Software S.L.U. All Rights Reserved. Information in this document is subject to change without notice. The software described in this document is furnished under a license agreement or nondisclosure agreement. The software may be used only in accordance with the terms of those agreements.
- Page 3 ASCII EIA-232 or TCP/IP enabled control systems. One single model is available for this gateway, with the following order code: IBOX-ASCII-KNX Model supporting up to 4000 internal datapoints. 3 / 36 © Intesis Software S.L.U. - All rights reserved http://www.intesisbox.com...
-
Page 4: Table Of Contents
Points definition .................... 9 KNX TP-1 (EIB) interface of IntesisBox .............. 10 Description ....................10 Points definition ..................11 LinkBoxEIB. Configuration & monitoring tool for IntesisBox KNX series ....12 Introduction ....................12 Project definition ..................12 Connection configuration ................18 Signals configuration ................... -
Page 5: Description
From now on, and with the aim of easy the read of this document, just the word "IntesisBox" will be used instead of the full gateway model description "IntesisBox ASCII Server - KNX". The aim of this integration is to make accessible signals and resources of any KNX/EIB system or device from any system capable of "talking"... -
Page 6: Functionality
® User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX 1.2 Functionality The integration operation is as follow: From the KNX system point of view, after the start up process, the gateway reads the points configured to be read at the start, and remains listening for changes of value of group addresses associated to internal datapoints. -
Page 7: Capacity Of Intesisbox
IntesisBox. Each datapoint can be associated to a different KNX group address. *These maximum values can be extended on demand. One single model is available for IntesisBox ASCII Server – KNX gateway, and it support up to 4000 internal datapoints. Ref.: IBOX-ASCII-KNX 7 / 36 ©... -
Page 8: Ascii Interface Of Intesisbox
® User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX 2. ASCII interface of IntesisBox This section describes the ASCII interface of the gateway, its configuration and functionality. 2.1 Description The gateway can be connected to any ASCII enabled device using its EIA232 interface (DB9 connector DTE), and offers through this interface the possibility of supervision and control of its internal datapoints using simple ASCII messages. -
Page 9: Points Definition
® User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX \r means carriage return character (HEX 0D, DEC 13). Message informing about a point's value (sent spontaneously by the gateway when receiving a change from KNX or sent by the gateway in response to a previous poll for the point): >Daaaa=vv\r... -
Page 10: Knx Tp-1 (Eib) Interface Of Intesisbox
User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX 3. Konnex TP-1 (EIB) interface of IntesisBox This section describes the KNX part of the gateway's configuration and functionality. This section assumes the user is familiar with KNX technology and technical terms. -
Page 11: Points Definition
® User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX 3.2 Points definition Every point defined in the gateway has the following KNX(EIB) features associated to it, which can be configured (optionally or mandatory depending on the feature): Feature... -
Page 12: Linkboxeib. Configuration & Monitoring Tool For Intesisbox Knx Series
IntesisBox and the use of some tools for monitoring and debugging de device. Some of these tools will be explained in this document but only some of them, the rest of available debugging tools and commands will not be explained here because they are for exclusive use under the recommendations of Intesis Software technical support. - Page 13 ® User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX Project selection window To create a new project, select a project using the same external protocol you want to use in the new project and push New button. You will be prompted to create a copy of the selected project (useful for similar installations) or create a brand new one.
- Page 14 IntesisBox and the PC running LinkBoxEIB must be established (working on-line). To do so follow these steps: 1. Make sure IntesisBox is powered-up a correctly connected to the KNX system via the EIB bus and to the ASCII system via the EIA-232 connection or TCP/IP connection (consult details for connection and pin assignments in section Connections of this document).
- Page 15 1. Check the checkbox off-line under the menu bar (it will change automatically to on- line) and LinkBoxEIB will ask for INFO about the IntesisBox connected to it via the serial connection, if the connection is ok then IntesisBox will respond with its identification (this can be monitored in the IntesisBox Communication Console window, as showed below).
- Page 16 ® User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX 16 / 36 © Intesis Software S.L.U. - All rights reserved http://www.intesisbox.com This information is subject to change without notice Email info@intesisbox.com +34 938047134 IntesisBox ® is a registered trademark of Intesis Software SLU...
- Page 17 IntesisBox ASCII Server - KNX To monitor the communication between IntesisBox and the external system (ASCII in this case), select the menu View -> Bus -> External system. The External protocol communication viewer window will be opened. This window shows in real time all the communication frames between IntesisBox and the ASCII device as well as debugging messages referent to external protocol (ASCII) sent by IntesisBox.
-
Page 18: Connection Configuration
1. Enter the physical address desired for IntesisBox inside the KNX network. 2. Check this if you want IntesisBox to force the readings in KNX of those points configured with "U" or "U2" flag after a KNX bus reset detection. - Page 19 6. Enter the IP NetMask for the gateway (supplied by the network administrator). 7. Enter the Default gateway address (Router address) in case the gateway (IntesisBox) is in a different sub network than the other ASCII TCP/IP devices (supplied by the network administrator).
-
Page 20: Signals Configuration
IntesisBox ASCII Server - KNX Signals configuration Select the Signals tab to configure the signals list (the IntesisBox's internal datapoints). Signals list 1. #. Signal’s number (edit not permitted). Every row in the grid corresponds to a signal (datapoint). Signals (rows in the grid) can be added or deleted selecting the desired row and clicking Add or Delete buttons. - Page 21 KNX system if this flag is activated. Possible values: “T” or blank. “T” means flag activated. 14. U. Indicates if this signal will be updated whenever IntesisBox starts up or after an EIB bus reset. “U” means flag activated for the main EIB group address (a read of the main EIB group address will be performed in the KNX system for the update).
- Page 22 ® User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX Useful tips for a more quick and comfortable use and configuration of the signals table: The columns Spon, EIS, R, W, T, U and Active can be modified selecting one or just more than one consecutive cells in the same column and using the contextual menu appearing with mouse right button click over the cells selected.
- Page 23 ® User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX 4. Enter the increment between consecutive assignments. For example selecting 1 for the first value and an increment of 1, the values generated will be 1,2,3,4,5.. and so 23 / 36 ©...
-
Page 24: Remember
If "W" is not activated, no write on the group address could be done from KNX, neither ▪ on the links (listening addresses). If "U" is activated, after IntesisBox start-up or a KNX bus reset, READ Requests will be ▪ sent to KNX to update the sending group. -
Page 25: Saving The Configuration And Sending It To Intesisbox
When the configuration is finished, click on button Save to save it to the project folder on hard disk. You will be prompted to generate the configuration file to send to IntesisBox, if you select Yes, the binary file containing the configuration for IntesisBox will be generated and saved also into the project folder. -
Page 26: Signals Viewer
This window shows all the active IntesisBox's signals with its main configuration parameters and its real time value in the column Value. After a reset of IntesisBox or after sending a configuration file to the IntesisBox, all the signal's values will be updated automatically in... -
Page 27: System Commands
To send a command to IntesisBox just select it from the list, or type it with the correct format, and press Enter or click on button Send. IntesisBox will act accordingly with the command received;... -
Page 28: Files
User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX 4.7 Files LinkBoxEIB saves IntesisBox configuration in the following files inside the project folder: PROJECT.INI .ini file containing general information referent to the project ASCII.INI .ini file containing the information referent to the connection window and other special adjustments ASCII.DAT... -
Page 29: Integration Of Intesisbox In Ets
To do so a Dummy device can be used in ETS to simulate the IntesisBox and associate also to this dummy device all group addresses used in IntesisBox http://www.intesis.com/down/eib/Dummy_Intesis.zip... -
Page 30: Setup Process And Troubleshooting
(see format above in this document) should be configured in the ASCII enabled device. It is necessary to have an EIB bus connection near IntesisBox with all KNX devices willing to integrate connected to this EIB network and correctly configured and commissioned. - Page 31 8. Open the ASCII Communication Viewer window (menu View -> Bus -> ASCII), force some point's polling from the ASCII device connected to IntesisBox, and check that there is communication activity, some TX frames and some other RX frames. This means that the communication with the ASCII device is ok.
- Page 32 ® User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX 32 / 36 © Intesis Software S.L.U. - All rights reserved http://www.intesisbox.com This information is subject to change without notice Email info@intesisbox.com +34 938047134 IntesisBox ® is a registered trademark of Intesis Software SLU...
-
Page 33: Connections
® User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX Connections KNX TP-1 Power (Bus EIB) See technical characteristics ASCII TCP/IP Ethernet RJ45 CMN 24Vac 9 - 30Vdc KNX TP-1 Max.125 mA 24Vac ® IntesisBox Max.127mA 50-60Hz www.intesis.com ASCII... - Page 34 ® User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX IntesisBox ASCII (EIA-232) Connection LiteTouch (DB9 M) (DB9 M) Cable EIA-232 Cable (DB9 F) (Crossed) (DB9 F) IntesisBox PC (LinkBoxEIB) Connection (DB9 F) (DB9 M) Cable EIA-232 Cable (DB9 M)
-
Page 35: Mechanical & Electrical Characteristics
® User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX 8. Mechanical & electrical characteristics Enclosure Plastic, type PC (UL 94 V-0). Dimensions: 107mm x 105mm x 58mm. Colour Light Grey. RAL 7035. Power 9 to 30Vdc +/-10% 1.4W. -
Page 36: Dimensions
® User’s Manual v10 r14 eng IntesisBox ASCII Server - KNX 9. Dimensions Ethernet port + Power port EIA-232 port Console 58 mm port 107 mm 105 mm Free space recommended to install the device into a cabinet (wall or DIN rail mounting),...
