Also the following functionality is supported by the gateway:
For every point, in the KNX part, one main group address (the sending group address) and
different listening group addresses can be defined. With this, from KNX, every point can be
addressed not only using its main group address but also using the other defined listening
addresses for the point.
Any change in a gateway's point with the feature "T" activated (in the KNX part), will force
the transmission of this point value with the corresponding telegram to the KNX system.
When the gateway starts up, or after an KNX bus reset, all the points with the feature "U"
or "U2" activated (in the KNX part) will be forced to be read in the KNX system to update its
values in the gateway's internal memory.
Any point with the feature "W" activated (in the KNX part), can be written in any moment
from the KNX system.
Any point with the feature "R" activated (in the KNX part), can be read in any moment from
the KNX system.
All the mentioned features (W,R,T,U) related to the KNX part are configurable per every
point in the gateway, with only a few necessary restrictions (see below in this document).
KNX-EIB EIS (data types) supported are: switching (1 bit), dimming (4 bit), float (16 bit),
scaling (8 bit), drive control (1 bit), priority (2 bit), float IEEE (32 bit), counter (8 bit),
counter (16 bit), counter (32 bit), ASCII char (8 bit).
