Mechanical & Electrical Characteristics - IntesisBox KNX TP-1 (EIB) User Manual

®
IntesisBox BACnet/IP Server - KNX
7. Mechanical & electrical characteristics
Enclosure
Color
Power
Terminal wiring (for
power supply and
low-voltage signals)
Mounting
BACnet/IP port
KNX port
LED indicators
Push buttons
Console port
Configuration
Firmware
Operational
temperature
Operational humidity 5% to 95%, non condensing
Protection
RoHS conformity
Norms and
standards
1
Not operational for the moment. Reserved for future use.
2
Standard cable DB9male-DB9female 1,8 meters long is supplied with the device for connection to a PC COM port for
configuring and monitoring the device. The configuration software, compatible with Windows
supplied.
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SL
Plastic, type PC (UL 94 V-0).
Dimensions: 107mm x 105mm x 58mm.
Light Grey. RAL 7035.
9 to 30Vdc +/-10%, Max.: 125mA.
24Vac +/-10% 50-60Hz, Max.: 127mA
Must use a NEC Class 2 or Limited Power Source (LPS) and SELV
rated power supply.
Plug-in terminal block for power connection (2 poles).
Per terminal: solid wires or stranded wires (twisted or with ferrule)
2
1 core: 0.5mm ... 2.5mm
2
2 cores: 0.5mm ... 1.5mm
3 cores: not permitted
Wall.
DIN rail EN60715 TH35.
1 x Ethernet 10Base-T (RJ45).
1 x KNX TP-1 (EIB) port opto-isolated. Plug-in terminal block (2
poles). TNV-1
1 x Power.
2 x KNX port activity (Tx, Rx).
2 x Ethernet port link and activity (LNK, ACT).
1 x KNX programming/bus.
1 x KNX programming.
EIA232. DB9 female connector (DCE). SELV
2
Via console port.
Via Ethernet
Allows upgrades via console port.
0°C to +70°C
IP20 (IEC60529).
Compliant with RoHS directive (2002/95/CE).
CE conformity to EMC directive (2004/108/EC) and Low-voltage
directive (2006/95/EC)
EN 61000-6-2, EN 61000-6-3,EN 60950-1, EN 50491-3
2
2
1
1
URL http://www.intesis.com
Email info@intesis.com
tel +34 938047134
User's Manual r18 eng
®
operating systems, is also
30 / 31
