IntesisBox KNX TP-1 (EIB) User Manual page 22

®
IntesisBox BACnet/IP Server - KNX
Description BACnet object instance number for the point. It can be manually entered by
the user or can be automatically assigned by LinkBoxBacnet when saving the
configuration (section 5.1.3)
Restrictions All the object instance numbers for objects of the same type must be
different
Comments It is recommended to let LinkBoxBacnet assign automatically object instance
numbers for the points
Description Indicates if the signal is active or not for the integration
• 0: Not active
Values
• 1: Active
Description Select a type for the BACnet Units
Values
Restrictions Only for the analog objects
Comments Edit using the mouse right-button-click pop-up menu
Description Checkbox that controls the Bac. Name format
• Checked: special format (Check Bac. Name table for details)
Values
• Not checked: Bac. Name = Description
Comments Check Bac. Name table for details
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SL
•
Area: Square Meters, Square Feet, etc.
•
Electrical: Amperes, Ohms, etc.
•
Light: Lumens, Luxes, etc.
•
Mass: Kilograms, Pounds Mass, Tons.
•
Pressure: Bars, Pascals, etc
•
Time: Years, Months, etc.
•
Temperature: Degrees Celsius, Degrees Kelvin, etc.
•
Etc.
Auto Bac. Name
Bac.ID
Active
Units
