IntesisBox
BACnet/IP Server - KNX
8. Dimensions
58 mm
107 mm
Free space recommended to install the device into a cabinet (wall or DIN rail mounting),
with space enough for external connections:
100 mm
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox
is a registered trademark of Intesis Software SL
Console
port
115 mm
Ethernet port
+ Power
105 mm
URL
Email
tel
User's Manual r18 eng
KNX
port
130 mm
http://www.intesis.com
info@intesis.com
+34 938047134
31 / 31
