IntesisBox KNX TP-1 (EIB) User Manual page 19

®
IntesisBox BACnet/IP Server - KNX
Description Main KNX group address for the signal. Flags R,W,T,U explained below will
only apply for this main KNX group address, not for listening addresses.
Values Group address in one of the following formats:
Restrictions Duplicated groups are not allowed
Empty groups are allowed, but only if they have just W activated and one or
more listening addresses.
Description KNX group addresses that will be listened by IntesisBox for this signal. If
IntesisBox receives a KNX telegram whose destination is one of these
listening addresses, the telegram will be taken into account and the
corresponding action will be performed on this signal.
Values Group addresses in one of the following formats:
More than one address can be entered, comma separated.
Restrictions It is not allowed a listening address that is the same as the sending group
(circular reference).
Listening addresses are not allowed if the flag W is not activated. Without W
activated, the listening addresses would not work.
Description Indicates if this signal is allowed to be read from KNX system.
Values
Restrictions Can't be active when the BACnet signal are AI, BI or MI
Needs the T flag active and therefore the software activates it automatically
Can't be simultaneously active with flag U and it is disabled if that flag is
activated. It has no restriction with U2
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SL
•
P/I/S
•
P/S
•
Single level (value 1 to 32767)
Listening addresses
•
P/I/S
•
P/S
•
Single level (value 1 to 32767)
• "R": flag activated
• Blank: flag not activated
Group
R
