IntesisBox KNX TP-1 (EIB) User Manual page 20

®
IntesisBox BACnet/IP Server - KNX
Description Indicates if this signal is allowed to be written from KNX system.
Values
Comments If it is not active, no write on the group address neither on the listening
addresses could be done from KNX
KNX Update telegrams (responses to Read) are handled in the same way as
Write telegrams, in all cases.
Description Indicates if this signal will generate a telegram sending to the KNX system
following a change of the signal's value, that is to say, any change of value
of this signal in BACnet side will be transmitted to the KNX system if this flag
is activated.
Values
Restrictions Can't be active when the BACnet signal are AI, BI or MI
Description Indicates if this signal will be updated (sending read requests) whenever
IntesisBox starts up or after a KNX bus reset.
Values
Restrictions Needs the W flag active and therefore the software activates it automatically
When "U" is selected it disables the R flag.
Comments DO NOT BE CONFUSED: Philosophy of IntesisBox point's U flag is not
the same as KNX device's U flag. In KNX devices, U flag means that
the point's value will be updated whenever a write telegram for the
group address is received by the device.
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox is a registered trademark of Intesis Software SL
• "W": flag activated
• Blank: flag not activated
• "T": flag activated
• Blank: flag not activated
• "U": flag activated for the main KNX group address. A read of the
main KNX group address will be performed in the KNX system for the
update.
• "U2": flag activated for the first listening address defined. A read of
the first listening address defined for the point will be performed in
the KNX system for the update).
• Blank: flag not activated
W
T
U
