IntesisBox
BACnet/IP Server - KNX
5. LinkBoxBacnet. Configuration & monitoring of IntesisBox BACnet
series
How to install and use the LinkBoxBacnet is explained in its Manual. It can be found in the
installation folder (if the Software is already installed) or it can be downloaded from the link
that can be found in the installation sheet supplied with the IntesisBox.
In this section only the specific project configuration for IntesisBox BACnet/IP Server - KNX
is going to be explained.
The External Protocol in this IntesisBox is KNX
5.1 Project configuration
To configure the integration connection parameters, and the points list, click on Config in
the Button Bar (Figure 5.1). The KNX Configuration window will be opened. For integrations
with a large number of points an alternative CSV based configuration method is explained in
in the LinkBoxBacnet Manual.
5.1.1 Connection configuration
Two subsets of information are configured using this window, the BACnet/IP parameters of
the IntesisBox, and the parameters of the KNX interface.
© Intesis Software S.L. - All rights reserved
This information is subject to change without notice
®
IntesisBox
is a registered trademark of Intesis Software SL
Figure 5.1 Menu and Button Bar in LinkBoxBacnet
User's Manual r18 eng
URL
http://www.intesis.com
Email
info@intesis.com
tel
+34 938047134
14 / 31
